Unibus board list
tbd, boards I have or that I would like to have, with relevant info
Check Henk's board list for details.
PDP 11/44
| Want/#Have | Board | Number | Description |
|---|---|---|---|
| Want | KE44-A | M7091 | 11/44 CIS Control Store |
| Want | KE44-A/2 | M7092 | 11/44 CIS Data Path / Logic module |
| 2 | PF11-F | M7093 | 11/44 Floating Point |
| 2 | KD11-Z | M7094 | 11/44 Data Path module |
| 2 | KD11-Z | M7095 | 11/44 Control module |
| 2 | KD11-Z | M7096 | 11/44 Multifunction module |
| 2 | KK11-B | M7097 | 11/44 4KWord cache module |
| 2 | KD11-Z | M7098 | 11/44 UNIBUS Interface |
| 4 | MS11-PB | M8743 | 512KB ECC RAM (AA) |
PDP 11/10 (11/05)
| Want/#Have | Board | Number | Description |
|---|---|---|---|
| 4 | ????? | G109C | Control and data loops for H214, with 2 extra parity bit channels |
| 0 | MM11-L | G110 | Control and data loops for H214, without the 2 extra bit parts populated (same PCB as G109) |
| 2 | ML11-L | G231E | Memory driver for H214, 16K X/Y Selection, Current source, Address Latch, 8K Decode |
| 4 | MM11-L | H214 | 8-Kword 16-bit memory stack (with G110 and G231) (replaced by H215) |
| 4 | KD11-B | M7260 | 11/05 data path module |
| 3 | KD11-B | M7261 | 11/05 control module, 2x revision E, 2x revision F |
| 1 | MM11-S | - | extension backplane which can hold a single MM11-L board set. |
There was some confusion. The stickers on the bags with boards marked two G109 boards as G110, and the 1973 drawings also specify the G110 as part of the 11/05. Apparently both boards use the exact same PCB (which is marked as G109C), but the G110 leaves out chips for two extra "parity" channels (details from Gunkies).
Common DEC cards
| Want/#Have | Board | Number | Description |
|---|---|---|---|
| 2 | DHU11-M | M3105 | 16 line async NUX with DMA |
| 1 | DELUA | M7521 | Ethernet interface |
| 2 | RL11 | M7762 | RL02 Disk controller. Both repaired. |
| 2 | DZ11-A | M7819 | 8-line double buffered async rs232/EIA with modem control |
| Want | DL11-W | M7856 | Serial line unit w/ real time clock |
| 1 | RX211 | M8256 | RX02 floppy disk interface, repaired |
| 1 | H317-E | RS232/EIA Distribution panel (16x) | |
| 2 | CR-11/CM-11 | M8291 | Card reader controller (punch card reader) |
| --------- | --------- | ------- | ------- |
| 2 | DiodeRom | M792 | 32-word 16bit ROM Diode matrix |
| 1 | Terminator | M9312 | Bootstrap terminator with 5 empty ROM sockets; one for CPU diagnostics, 4 for peripheral boots |
| 2 | DL11 | M7800 | Async transmitter & receiver 110-2400baud |
| 7 | DR11-C | M7860 | M786+M105+M7821; general device interface to PDP11 |
Emulex
| Want/#Have | Board | Description |
|---|---|---|
| 2 | TC12 | Pertec tape controller |
